Firefly Vertical Panel Radiators
IDEAL WITH HEAT PUMPS
- Modern Contemporary Vertical Design
- Factory Fitted Designer Cover
- Single Body Slim Line Vertical Design
- Available in 500mm and 600mm lengths and up to 2000mm in height
- 1/2” TBOE Connections As Standard
- Made and Tested in Accordance with BS EN 442
- Durable Powder Coat RAL 9016 Finish
- 10 Year Conditional Warranty
- All radiators tested to 13 bar which exceeds operating pressure of 10 bar
- All radiators are double wrapped to ensure maximum protection
- Low water content combined with modern welding technology and maximum metal gauge material creates a highly efficient product with the capability of a fast heat up time.
Vertical Panel Radiators: Size and Output Specifications
 | Length | 500mm | |
|---|---|---|---|
| inches | 20" | ||
| Height | Height | OUTPUT | |
| mm | inches | Watts | BTU |
| 1600 | 63" | 1861 | 6351 |
| 1800 | 70" | 2094 | 7146 |
| 2000 | 79" | 2327 | 7941 |
| Length | 600mm | |
|---|---|---|---|
| inches | 24" | ||
| Height | Height | OUTPUT | |
| mm | inches | Watts | BTU |
| 1600 | 63" | 2147 | 7326 |
| 1800 | 70" | 2416 | 8242 |
| 2000 | 79" | 2684 | 9158 |
| Heat Outputs are based on a Delta T of 62. | |||
